DGA status & interpretation: navigate the standards through real cases
Hosted by: Anatoliy Mudryk / Free
SIGN UP
If you are already a subscriber of the Transformers Academy or Transformers Maagazine, please, Login
with your credentials..
The session answers typical questions such as:
- What is the DGA condition of my transformer?
- What is the failure mode?
- What standard shall I use?
A simpler DGA status based on four levels is defined and adapted to each guideline in order to have comparable results independently on the standard used.
A simple graphical method is also proposed to group all the available interpretation methods in a single chart, making the DGA result interpretation intuitive and immediate.
Both the interpretation chart and the DGA status are then used and validated through real cases , including those described in CIGRE TB771.
About the author
Anatoliy Mudryk
Camlin•Received Electrical and Mechanical Engineering degree in 1996
•Transformer expert for transformer’s reliability, design improvement, monitoring and diagnostics.
•Professional life includes ZTR, ZTZ-Services, GE Kelman and Camlin Energy.
•member of CIGRE and IEEE transformer working groups
•Author and co-author of several technical papers and presentations
